GENSET CONTROLLER PRICE
In this page, the genset controller prices of Be21, Be22, Be42, and Be142 were made between 1980 to 2015.
BE142 NFPA-110 & CSA M89 COMPLIANT GENSET CONTROLLER
The Be142 is a 3-phase NFPA110-COMPLIANT genset controllerì and upgrades the most popular Be21 and Be42 controllers.
A high-luminosity display shows parameters, alarms, and operating functions. The Be142 controller interfaces with resistive or digital sensors. It measures Vac, Aac, Vdc, Hz, hour count, R.p.m., Oil Pressure, Engine Temperature, Battery Vdc and Fuel Level. Software for remote monitoring is also provided free of charge. The Be142 provides MODBUS via RS485 and complies with NFPA-110 / NFPA-99. Install our TCP-IP server to monitor and control the Be142 via the INTERNET.
BE142 GENSET CONTROLLER PRICE
329€
FREE-SHIPPING
DELIVERY TIME 20 DAYS
The Be142 is designed to drive two contactors. A good practice practice, in addition to the The output of the Be142 is suitable for automotive relays 12V or 24V (according to the engine's battery). The Be142 outputs are short-circuited proof, but we recommend that you connect all the time with flywheel relays.
THE Be142 CONTROLLER REAR VIEW
All connections are made via removable female connectors.
1) RS485 4-POLES PLUG 2) DIGITAL INPUTS 3) ENGINE INSTRUMENTS INPUTS 4) POWER SUPPLY AND ENGINE RUNNING CONNECTIONS 5) GENERAL PURPOSE OUTPUTS 6) CURRENT TRANSFORMERS CONNECTIONS 7) MAINS AND GENERATOR VOLTAGE CONNECTIONS 8) REAR COVER SCREWS 9) 4 X M4 FIXING NUTS
UPGRADING A BE42 CONTROLLER WITH BE142
The Be142 shares the same low-voltage connection as the Be42 controller. The Be42 monitors 3-phase of MAINS but only two phases of the GENERATOR. The Be42 features only one input for a current transformer. The Be142 is a fully 3-phase AMF controller. When you are going to replace an old Be42, we recommend that you install the Be142. It is not only 3-phase, but it has additional features about MAINS and GENERATOR monitoring. You can see in the picture the requirement from the connection point of view.
You are required to remove the 3 wires of the MAINS connection. You must replace the old connector with a 5-pole with the new one with 3 poles only. After that, you remove the old 3-pole connector for the generator and replace it with the new one. As you can see from the picture, Phase 3 of the GENERATOR remains unconnected. Finally, you are required to replace the code [0] with the code [1] into parameter P(. This will instruct to monitor a 3-phase system on the MAINS and only 2-phase on the GENERATOR. You will benefit of a new updated software running on your standby system.
BE42 GENSET CONTROLLER PRICE
The Be42 is a genset controller that features a high-luminosity display. The Be42 controller interfaces with analogue or digital sensors. It measures Vac, Aac, Vdc, Hz, hour count, R.p.m., Oil Pressure, Engine Temperature, Battery Vdc and Fuel Level. Software for remote monitoring is also provided free of charge. The Be42 provides MODBUS via RS485. The Be42 complies with NFPA-110 / NFPA-99. By using our TCP-IP server, you can monitor and control the Be142 via INTERNET. An option for remote control by GSM is also provided. Be42 features 3-phase monitoring for MAINS and 2-phase monitoring for generator
BE42 PRICE
364€
FREE SHIPPING TO EU ONLY
DELIVERY TIME 20 DAYS
BE22 GENSET CONTROLLER PRICE
The Be22 AMF controller is a cost-effective 3-phase AUTOMATIC MAINS FAILURE controller with 3-phase Generator Control and automatic engine control. It provides metering and alarm monitoring via Display and LEDs. The module is operated via push buttons. A mimic diagram with LED indication provides information regarding the status of the Mains, Generator and modes of operation. 2 separate modules make the BE22 save time for assembling the panel.
The BE22 includes a cable for the connection of the two boards and connectors. Be22 key features:
- Includes Fuses for protection of the coil of the contactors
- Ideal solution for cost-effective panel
- 30 programmable parameters - 7Vdc up to 33Vdc supply
- Multifunction display includes h-meter
-RELAY OUTPUT short circuit proof
- Vac-Aac-Hz-Rpm-Vdc display indications
YOU CAN ONLY REPLACE THE BE22 WITH BE242
Replace the AMT910 AMT920 and BE11 controller with
BE21 GENSET CONTROLLER
The Be21 is a single-phase automatic mains failure controller. It provides metering and alarms via display and LEDs. The operation of the module is via push buttons. A mimic diagram with LEDs indication provides information regarding the status of the Mains, the Generator and the mode of operation. Key features: - 30 programmable parameters - 7Vdc up to 33Vdc supply - Multifunction display includes hour-meter - Vac-Aac-Hz-Rpm-Vdc display indications. The Be21 is suitable for single-phase automatic mains failure panels suitable for critical applications like military power systems and telecom applications.
Be21 AMF CONTROLLER INSTALLATION
BE21 PRICE
FREE SHIPPING
DELIVERY TIME 7 DAYS
